CENTRIFUGAL PUMPS

Horizontal Axially Split Casing pumps
(Single Stage)

Range

Delivery size up to 50 mm to 1100 mm (2" to 43"), Capacity 20,000 m3/hr (88060 USgpm), Head up to 160 meters (512 ft), Temperature 10oC to 90oC

Application

Air-Conditioning, Fire Fighting, Irrigation,Paper,Sugar,Textile Mills,Power Plants, Water Supply

Horizontal Axially Split Casing Pumps

Range

Delivery size from 50 mm to 350 mm (2" to 14"), Capacity 45,00 m3/hr (19814 USgpm), Head up to 330 meters (1056 ft), Temperature 10oC to 100oC

Application

Air-Conditioning, Refregeration System, Fire Protection Systems and Mining, Petroleum Refineries Water/liquids with slight impurities

Horizontal Axially Split Casing pumps
(Two Stage)

Range

Delivery size up to 50 mm to 150 mm (2" to 6"), Capacity 470 m3/hr (2069 USgpm), Head up to 180 meters (576 ft), Temperature 10oC to 90oC

Application

Air-Conditioning, Fire Fighting, Irrigation,Mine drainage,Power Plants, Water Supply

Multistage Pumps

Range

Delivery size from 32 mm to 250 mm (11/4" to 10"), Capacity up to 850 m3/hr (3145 USgpm), Head up to 850 meters (2720 ft), Temperature 40oC to 140oC

Application

Boiler feed, Booster Service, Fire fighting, Mine Dewatering

Multistage Pumps

Range

Delivery size from 50 mm to 300 mm (2" to 12"), Capacity up to 1000 m3/hr (4400 USgpm), Head up to 750 meters (2400 ft), Temperature 10oC to 90oC

Application

Booster Service, Fire-fighting, Irrigation, Mine Dewatering

Side Channel Pumps

Range

Delivery size from 25 mm to 50 mm (1" to 2"), Capacity 20 m3/hr (88 USgpm), Head up to 315 meters (1008 ft), Temperature 40oC to 120oC

Application

Air Conditioning, Boiler Feed , Domestic Petroleum, Chemical and, Process Industry

In Line Vertical Multistage Pumps

Range

Delivery size up to 100 mm (4"), Capacity up to 75 m3/hr (330 USgpm), Head up to 220 meters (704 ft), Temperature 15oC to 120oC

Application

Booster, Firefighting, HVAC Boiler feed, condensate/DM water Pressurised cleaning systems Drip and sprinkler irrigation Purified water, food, pharma sectors Reverse Osmosis, water treatment

Domestic Monoblocs Pumps

Range

Delivery size 20 mm and 25 mm (3/4" and 1"), Capacity up to 3200 LPH (3.2m3/hr) (14 USgpm), Head up to 50 metres. (160 ft) , Power rating 0.18 kw to 0.75 kw (0.25 hp to 1.0 hp)

Application

Apartments, villas , Booster services , Gardening , Hospitals, hotels

Self Priming Slow Speed Monoblocs Pumps

Range

Delivery size 25 mm (1") , Capacity up to 4m3/hr (18 USgpm), Head up to 40 metres. (128 ft), Power rating upto 0.75 kw (1.0 hp)

Application

Booster Services , Domestic water supply , Washing in garages and , laundries , Industries

End Suction Single Stage Monoblocs Pumps

Range

Delivery size 25 mm to 100 mm (1" to 4") Capacity up to 133 m3/hr. (585 USgpm) Head up to 76 metres. (243 ft) Power rating 1.5 kw to 15 kw (2 hp to 20 hp)

Application

Agriculture , Industrial usage , Water supply

End Suction Single Stage Monoblocs Pumps

Range

Delivery size 50 mm to 150 mm (2" to 6"), Capacity up to260 m3/hr (1144 USgpm), Head up to 22 metres (70 ft), Power rating 2.2 kw to 7.5 kw (3 hp to 10 hp)

Application

Irrigation, Water Supply

End Suction Single Stage Monoblocs pumps

Range

Delivery size from 32 mm to 65 mm (13/8" t0 21/8") , Capacity up to70 m3/hr. (308 USgpm) , Head up to 102 metres (326 ft) , Power rating 0.75 kw to 15 kw (1 hp to 20 hp)

Application

Agriculture, Industrial usage, Domestic water supply, Drinking water supply, water supply schemes

Monobloc pumps

<

Range

Delivery size up to 80 mm (25/8"), Capacity up to 200 m3/hr (880 USgpm), Head up to 64 metres(205 ft), Temperature 0 30oC to 100oC

Application

Booster Service, Pumping Clear or turbid, water up to 3000 ppm, Sprinkler Irrigation

Vacuum pumps

Range

Vacuum up to , 650 mm (26") of Mercury, Air Flow Rate up to, 55 m3/hr (242 USgpm), Power rating 0.75 Kw, to 2.2 Kw (1 hp to 2 hp)

Application

Drying, Evaporation,, Distillation, Evacuation of air from, suction pipes and, chambers, Filtration, Sterilisation, Priming of large pumps, Twist drilling machine, bottle filling

Solids Handling Non—Clog pumps

Range

Delivery size 250 mm to, 900 mm (10" to 35"), Capacity up to, 13000 m3/ hr, (57,240 USgpm), Head up to 82 metres, (262 ft), Temperature (—) 10oC, to 90oC

Application

Contaminated processliquids like sugar factory waste,trade liquors, For handling liquidswith solids in suspension,Pulpy material in paper Industries, Viscous liquids orpowdered material slurries

Non—Clog pumps

Range

Delivery size up to 450 mm (18"), Capacity up to 3400 m3/hr (14,970 USgpm), Head up to 55 metres (176 ft), Temperature (—) 10oC to 140oC

Application

Effluents, sewage, muddy,viscous, contaminated liquids containing solids insuspension, in sugar factories, sewage pumping stations, chemical, fertilizer, pulp and paper, food and steel industries.

End Suction pumps

Range

Delivery size up to 125 mm (5"), Capacity up to 660 m3/hr (2906 USgpm), Head up to 100 metres (320 ft), Temperature 10oCto 140oC

Application

Air conditioning, Condensate water supply, Fire fighting and Booster Services, Sprinkler system handling clear and turbid water upto 3000 ppm

End Suction Process pumps

Range

Delivery size from 25 mm to 80 mm (1" to 31/8"), Capacity up to 120 m3/hr. (528 USgpm), Head up to 70 metres (224 ft), Temperature 5oC to 90oC

Application

Fertilizer, Petrochemical, Refinery

End Suction Process pumps

Range

Delivery size from 20 mm to 200 mm ( 3/4" to 8"), Capacity up to 750 m3/hr (3300 USgpm), Head up to 150 metres (480 ft), Temperature 50oC to 350oC.

Application

Air-conditioning, Condensate extraction, Distilleries, Edible oil, sugar, textile and process industries., Water treatment plants

Solids Handling pumps

Range

Delivery size up to 200 mm ( 8" ), Capacity up to 2400 m 3/ hr (10567 USgpm), Head up to 90 metres (288 ft), Temperature 10oC to 140°C

Application

Powdered material slurries, Sewage , Sludge , Sugar factory waste

Vacuum pumps

Range

Vacuum up to 650 mm (26") of Mercury, Air Flow Rate up to 162 m3/hr (713 USgpm) Power-rating 3.7 kW to 7.5 kW (5.0 hp to 10.0 hp)

Application

Drying, Evaporation,, Distillation, Filtration, Sterilisation,, Evacuation of air from suction pipes and chambers, Priming of large pumps, Twist drilling machine, bottle filling

Self—Priming pumps

Range

Delivery size from 40 mm to 150 mm (13/8" to 6"), Capacity up to 275 m3/hr (1210 USgpm), Head up to 34 metres (109 ft), Power rating 0.75 Kw to 19.5 Kw (1 hp to 27 hp)

Application

Sewage/ muddy water, Trash

Two Stage End Suction pumps

Range

Delivery size from 40me to 6.5 mm (13/8" to 21/8") , Capacity up to68 m3/hr (300 USgpm), Head up to 104 metres (333 ft), Power rating 3.7 Kw to 15 Kw (5 hp to 20 hp)

Application

Irrigation, Sprinkler irrigation, Water supply

Two Stage End Suction pumps

Range

Delivery size up to 25 mm (1") , Capacity up to 2880 litres per hour (13 USgpm) , Head Up to 54 metres (173 ft) , Power Rating 037 kW to 1.1 kW (0.5 hp to 1.5 hp)

Application

Domestic pressure boosting Irrigation, Water supply for domestic, Industries for clear water handling

Jet pumps

Range

Delivery size from 25 mm to 40 mm (1 to 13/8") , Capacity up to 8.9 m3/ hr. (40 USgpm) Depth up to 48 metres (154 ft), Power rating 0.37 kw to 2.2 kw (1 hp to 3 hp)

Application

Gardening, nursery, Water supply

Jet pumps

Range

Delivery size 150 mm to 300 mm (6" to 12"), Capacity up to 1900 m3/hr (8866 USgpm), Head up to 35 metres (112 ft), Temperature (r)10oC to 90oC

Application

Aqua Culture , Irrigation, Sugar Industries, water supply

End Suction pumps

Range

Delivery size from 20 mm to 200 mm (3/4" to 8"), Capacity up to 750 m3/hr (3300 USgpm), Head up to 150 metres (480 ft) , Temperature 30oC to 90oC

Application

Air—conditioning, Booster service , Fire fighting

End Suction pumps

Range

Delivery size from 200 mm to 650 mm (8" to 26") , Capacity up to 7000 m3/ hr (30,820 USgpm), Head up to 30 metres (90 ft), Temperature 5oC to 140oC

Application

Air—conditioning, Drainage, Irrigation, Storm water

Multistage pumps

(HORIZONTAL)

Range

Delivery size up to 65 mm (19/8"), Capacity up to 53 m3 / hr. (233 USgpm), Head up to 136 metres (435 ft), Power rating up to 19.0 kW (26 hp)

Application

Boiler feed, Dewatering in mines, Fire-Fighting, Sprinkler/Conventional, Irrigation, Water supply for domestic use

Multistage Pumps

(VERTICAL)

Range

Delivery size up to 65 mm (19/8"), Capacity up to 53 m3 / hr. (233 USgpm), Head up to 136 metres (435 ft), Power rating up to 19.0 kW (26 hp)

Application

Boiler feed, Dewatering in mines, Fire-Fighting, Sprinkler/Conventional, Irrigation, Water supply for domestic use

Submersible pumps

Range

Delivery size up to 100 mm (4") , Capacity up to 110 m3/hr (484 USgpm), Head up to 64 metres (205 ft) , Power rating 2.2 kW to 7.5 kW (3 hp to 10 hp)

Application

Agriculture, Irrigation, Sprinkler irrigation, Water supply

Belt Driven pumps

Range

Delivery Size up to 100 mm (4"), Capacity up to 170 m3/ hr. (750 USgpm), Head up to 38 metres (122 ft), Power rating 3.7 kW to 15 kW (5 hp to 20 hp)

Application

Agriculture (River/ Open well), Dugrcum-borewell, Water supply

End Suction pumps

Range

Delivery size from 32 mm to 150 mm (1 1/4" to 6"), Capacity up to 550 m3/hr. (2422 USgpm), Head up to 100 metres (320 ft), Temperature 10oC to 100oC

Application

Air-conditioning, Booster service, Fire fighting, Sprinkler systems

End Suction pumps

Range

Delivery size up to 100 mm (4”), Capacity up to 125 m3/ hr. (550 USgpm), Head up to 23 metres (74 ft), Power rating up to 5.9 Kw (8 hp)

Application

Irrigation, Industries for clear water handling, Water supply for domestic use

End Suction pumps

Range

Delivery size from 50 mm to 150 mm (2” to 6”) , Capacity up to 350 m3/hr. (1540 USgpm), Head up to 42 metres (134ft) , Power rating 2.2 kw to 18.33 kw(3 hp to 25 hp)

Application

Irrigation, Water Supply

End Suction pumps

Range

Delivery size from 25 mm to 50 mm (1” to 2”) , Capacity up to 44 m3/hr. (194 USgpm), Head up to 52 metres (166 ft), Power rating 0,25 kw to 7.5 kw (0.3 hp to 10 hp)

Application

Irrigation, Sprinkler Irrigation, Water supply

Inline pumps

,

Range

Delivery size from 40 mm to 100 mm (1 /8 ‘to 4), Capacity up to 210 m3/hr (925 USgpm), Head up to 65 metres, (208 ft), Temperature 30°C to 90°C.

Application

Air-conditioning, Booster service, Sprinkler systems

Canned Motor pumps

Range

Delivery size from 20 mm to 250 mm (3/4"to 10"), Capacity up to 1000 m3/hr (4400 USgpm), Head up to 135 metres (432 ft), Temperature 40°C to 250°C

Application

Nuclear power plants , Petrochemical plants , Refrigeration plants

Concrete Volute pumps

Range

Delivery size up to 4000 mm (160), Capacity up to 1,20,000 m3/hr (5,28,360 USgpm), Head up to 50 metres (160 ft), Motor rating up to 4500 Kw (6120 hp)

Application

Aqua Culture, Circulating, Water/Condenser,Cooling Water for Power, Plants,Desalination,Drainage and FloodControl,Dry Docks,Lift Irrigation and Water, Supply ,Storm Water
